419-08 Cellular Phone: Description And Operation (page 6 of 8)

CD / MP3 Changer
Touch Screen Display (TSD)
Note Pad
Navigation

Voice control will not control Television or climate control system.

On vehicles without navigation system fitted the voice recognition software is held in the Transceiver Module (TM) and the
microphone is hardwired directly into the TM. ON vehicles with navigation the voice recognition software is held in the
navigation computer and the microphone is wired directly into the navigation computer and the TM. Vehicles with only no
navigation system will have a slightly reduced functionality compared with vehicles that have navigation fitted as well as
the phone.

The TM only houses voice recognition software for the telephone system.

Voice control enables the driver to activate important functions of the car telephone and navigation systems without
needing to operate any controls manually. This allows the driver to concentrate fully on driving the vehicle. Whenever the
driver issues one of the defined voice commands with the system active, the voice control system converts the command
into a control signal for the telephone or navigation system. The system recognises which system the command is
directed at and routes the direction accordingly. The driver is guided through the dialogues by announcements or
questions.


Telephone

The telephone system allows the following to be accessed and controlled by the voice recognition function.

Dial Number

This allows the user to dial a number (up to 20 digits) by digit entry with editing facility and with number as built up and
displayed on the instrument pack message centre. The maximum number of recognised digits to be entered in one go is
16.

Phonebook

This allows the user to store inputted phone numbers against inputted nametag. Nametags are user repeatable
association names given to identify the numeric destination of the phone call.

This facility will allow 50 nametags with corresponding telephone numbers to be stored within the voice recognition
Phonebook. This phonebook should not be confused with the phonebook held within the Sim card or mobile phone. The
facility shall allow editing of the nametags and phonebook and also provide audible feedback of the recorded nametag.
Where nametags are part of the audible Feedback the corresponding phone number shall be displayed in text form on the
instrument pack message centre.

It is also possible to use the add name feature to enter a telephone number onto the IHU and then by voice recognition
append a nametag and store this within the voice recognition phonebook.


Radio

The radio system allows the following to be accessed and controlled by the voice recognition function.

Radio On

This allows the user to switch on the radio function. "Radio On" switches the ICE system to Radio with the last station
played.

Radio Tune

This allows the user to tune the radio the radio into the desired frequency and band.

Radio Presets

This allows the user to allocate frequency against a given band preset. The user must be tuned into the desired frequency
and band prior to preset allocation. If a preset has already a stored frequency and band against that preset then the new
frequency and band shall be allotted.
