413-08 Information And Message Center: Description And Operation (page 10 of 18)



Ambient Temperature

The external ambient air temperature is measured by a sensor located on the right hand side of the bonnet locking
platform, behind the front grill. The sensor is connected to the HEVAC module. The HEVAC module outputs temperature
messages on the CAN bus which are used by the instrument cluster to display the current ambient temperature.

The message center displays the ambient temperature in the top right hand corner of the LCD display. The temperature is
displayed until the message center is required to display system information. When system information has been
displayed, the ambient temperature will reappear. The temperature is displayed in ºF or ºC depending the market
configuration of the vehicle. The driver can also change the temperature reading using the 'Customer Settings' function.

Cold Warning Indication

When the ambient temperature is being displayed, if the temperature falls to 4ºC (39.2ºF) or below, the cold warning
symbol will display. The cold warning symbol is in the form of a snow flake and will flash on and off, five times at a
frequency of 2Hz. An audible warning will also be emitted by the instrument cluster to alert the driver. After the fifth flash
of the symbol, the display will continue to display the snow flake symbol in place of 'EXT' until a temperature of 6°C (42.8°
F) or higher is measured.

The cold warning will only be displayed once during an ignition cycle. If the ambient temperature rises to 6ºC (42.8ºF) or
above and then subsequently falls to 4ºC (39.2ºF) or below during the same ignition cycle, the warning will be repeated.

If the display mode changes to a mode which does not display the ambient temperature during the warning period, the

SWITCH TO RELEASE

PRESS FOOT BRAKE

OR CLUTCH AND

PARK BRAKE SWITCH

TO RELEASE

None

Park brake system release is

prevented until foot brake or clutch

pedal is pressed

Follow message instruction

PARK BRAKE FAULT

AUTO RELEASE NOT

FUNCTIONAL

Park brake amber

indicator permanently

illuminated

Drive away release function is not

operating

Use park brake switch and

foot brake to release

PARK BRAKE OFF

LIFT SWITCH TO

APPLY

Park brake red indicator

flashes

An emergency release operation has

been detected

Pull park brake switch to re-

engage emergency release

LOW WASHER FLUID

Single chime at ignition

on.

Washer fluid quantity below 1 litre

Add water and additive

mixture to washer bottle

HEADLAMP OFF

DELAY XX SEC

None

Driver has selected headlamp

feature by turning ignition off before

turning off headlamps

None

LOW COOLANT

LEVEL

None

Coolant level in header tank below

recommended level

Check coolant system for

leaks and top up to correct

levels

DRIVER'S DOOR

OPEN

None

Driver's door open or not fully closed

None

LEFT REAR DOOR

OPEN

None

Left rear door open or not fully closed

None

FRONT PASSENGER

DOOR OPEN

None

Front passenger door open or not

fully closed

None

RIGHT REAR DOOR

OPEN

None

Right rear door open or not fully

closed

None

TAILGATE OPEN

None

Tailgate open or not fully closed

None

BONNET OPEN

None

Bonnet open or not fully closed

None

SETTINGS

None

Driver has accessed the 'Customer

Settings menu

Use the steering wheel

switches to view and change

the settings menus or press

the trip computer button to

exit the setting menu

AUTOMATIC MODE

None

Driver has enabled the interior lamps

None
