TYRE PRESSURE

MONITORING SET
FOR HEAVY LOAD

indicator illumination.

TPMS switch status LED

illuminated.

TPMS system set by driver for heavy

load operation.

None

TYRE PRESSURE

MONITORING SET

FOR LIGHT LOAD

None

Normal setting for TPMS.

None

CHECK SPARE TYRE

PRESSURE

None

Pressure in spare tire decreased to

warning threshold.

Inflate tires to correct

pressure

FRONT LEFT TYRE

PRESSURE NOT

MONITORED

Chimes emitted for a

short time, amber

indicator permanently

illuminated. Chimes

emitted and amber

indicator permanently

illuminated at subsequent

ignition on cycles.

Possible loss of RF transmission or

defective sensor battery.

Connect T4 to diagnose fault

FRONT RIGHT TYRE

PRESSURE NOT

MONITORED

Chimes emitted for a

short time, amber

indicator permanently

illuminated. Chimes

emitted and amber

indicator permanently

illuminated at subsequent

ignition on cycles.

Possible loss of RF transmission or

defective sensor battery.

Connect T4 to diagnose fault

REAR LEFT TYRE

PRESSURE NOT

MONITORED

Chimes emitted for a

short time, amber

indicator permanently

illuminated. Chimes

emitted and amber

indicator permanently

illuminated at subsequent

ignition on cycles.

Possible loss of RF transmission or

defective sensor battery.

Connect T4 to diagnose fault

REAR RIGHT TYRE

PRESSURE NOT

MONITORED

Chimes emitted for a

short time, amber

indicator permanently

illuminated. Chimes

emitted and amber

indicator permanently

illuminated at subsequent

ignition on cycles.

Possible loss of RF transmission or

defective sensor battery.

Connect T4 to diagnose fault

PARK BRAKE FAULT

TO HOLD VEHICLE

REMOVE KEY THEN

APPLY PARK BRAKE

Park brake amber

indicator illuminates and

red indicator flashes

Loss of CAN or vehicle speed signal

is missing

The vehicle cannot be

parked by the park brake

system in the normal way

until the ignition key is

removed and a park brake

switch apply request is made

PARK BRAKE FAULT

SYSTEM NOT

FUNCTIONAL

Park brake red indicator

flashes

Possible motor fault when driver

requested a switch application

Connect T4 to diagnose fault

PARK BRAKE

BEDDING CYCLE

ACTIVE

Park brake red indicator

flashes

The park brake bedding cycle has

been initiated by the dealer

technician

Follow bedding-in procedure

in Service Procedures

manual

CAUTION! PARK

BRAKE APPLIED

Park brake red lamp

permanently illuminated

The park brake is applied when the

vehicle is moving

Do not use the park brake

system when the vehicle is

moving, except in an

emergency

PARK BRAKE FAULT

Park brake amber

indicator permanently

illuminates

Possible system malfunction

detected

Follow message instruction

PRESS FOOT BRAKE

AND PARK BRAKE

None

Park brake system release is

inhibited until footbrake is pressed

Follow message instruction
