Rear Driveshaft R&I (47.15.03)
- Make
- Land Rover
- Model
- Discovery LR3/Disco 3
- Section
- Rear Driveshaft R&I (47.15.03)
Rear Driveshaft (47.15.03)
Removal
1 .
WARNING: Do not work on or under a vehicle supported only by a jack. Always support the
vehicle on safety stands.
Raise and support the vehicle.
2 .
Remove the fuel tank heat shield.
Remove the 3 bolts and 2 nuts.
3 .
CAUTION: Mark the position of the driveshaft flange in relation to the drive pinion flange.
CAUTION: To avoid damage to the joint or gaiter, do not allow the driveshaft to hang.
Release the driveshaft from the transfer case drive flange.
Remove the 6 Torx bolts and washers.
4 .
CAUTION: Mark the position of the driveshaft flange in relation to the drive pinion flange.
CAUTION: To avoid damage to the joint or gaiter, do not allow the driveshaft to hang.
Release the driveshaft from the rear axle drive flange.
