Front Driveshaft R&I(47.15.02) (page 2 of 2)

Installation

6 .

  Remove the front driveshaft.

Compress the joints to disengage the drive flanges.

1 .

  Install the driveshaft.

Clean the components.

Compress the joints to engage the drive flanges.

2 .

  Attach the driveshaft to the front axle drive flange.

Tighten the new Torx bolts to 45 Nm (33 lb.ft), then a further 90 degrees.

3 .

  Attach the driveshaft to the transfer case drive flange.

Tighten the new Torx bolts to 45 Nm (33 lb.ft), then a further 90 degrees.

4 .

Install the exhaust system. For additional information, refer to

Exhaust System (30.10.08)

 (Section

309-00)

5 .

  Connect the battery ground cable. For additional information, refer to

Specifications

 (Section 414-00)
