Engine Td6

TORQUE WRENCH SETTINGS

06-2

Engine Td6

TORQUE DESCRIPTION

METRIC

IMPERIAL

Camshaft sprocket retaining screws

l

Stage 1

l

Stage 2

20 Nm
35

°

15 lbf.ft
35

°

Vacuum pump bolts

22 Nm

16 lbf.ft

Camshaft bearing cap screws

10 Nm

7 lbf.ft

Camshaft oil feed rail

10 Nm

7 lbf.ft

Timing chain tensioner access plug

30 Nm

22 lbf.ft

Crankshaft pulley bolt:

l

Stage 1

l

Stage 2

l

Stage 3

40 Nm
60

°

Further 60

°

30 lbf.ft
60

°

Further 60

°

Crankshaft rear oil seal housing:

l

M6 Bolts

l

M8 Bolts

10 Nm
22 Nm

7 lbf.ft
16 lbf.ft

Cylinder head bolts * +:

l

Stage 1

l

Stage 2 - Loosen all bolts

l

Stage 3 - Tighten all bolts

l

Stage 4 - Tighten all bolts

l

Stage 5 - Tighten all bolts

80 Nm

1

/

2

 Turn

50 Nm
90

°

Further 90

°

59 lbf.ft

1

/

2

 Turn

37 lbf.ft
90

°

Further 90

°

Cylinder head to timing cover Allen screws

20 Nm

15 lbf.ft

Timing chain guide upper pins ++

20 Nm

15 lbf.ft

Engine lifting bracket Torx screws

25 Nm

18 lbf.ft

Camshaft cover bolts

10 Nm

7 lbf.ft

Acoustic cover Allen screw

5 Nm

3.7 lbf.ft

Engine access cover bolts

5 Nm

3.7 lbf.ft

Engine to gearbox bolts

45 Nm

33 lbf.ft

Engine mounting to bracket nuts

100 Nm

74 lbf.ft

Gearbox to engine sump Torx bolts

22 Nm

16 lbf.ft

Closing plate to gearbox bolts

10 Nm

7 lbf.ft

Cross member bolts

68 Nm

50 lbf.ft

Engine rear mounting to cross member nut and bolt

100 Nm

74 lbf.ft

Engine left hand mounting bolts +:

l

Stage 1

l

Stage 2

20 Nm
Further 90

°

15 lbf.ft
Further 90

°

Engine left hand mounting to sub-frame bolts

100 Nm

74 lbf.ft

Engine bracket to engine left hand mounting nut

100 Nm

74 lbf.ft

Engine right hand mounting to sub-frame bolts

56 Nm

41 lbf.ft

Engine bracket to engine right hand mounting nuts

100 Nm

74 lbf.ft

Oil filter cap

25 Nm

18 lbf.ft

Oil pump pick-up strainer bolts

10 Nm

7 lbf.ft

Oil pump pick-up strainer support bracket bolts

10 Nm

7 lbf.ft

Oil pump drive gear Torx bolt

25 Nm

18 lbf.ft

Oil pump bolts

25 Nm

18 lbf.ft

Oil sump bolts:

l

M6 Bolts

l

M8 Bolts

10 Nm
22 Nm

7 lbf.ft
16 lbf.ft

Dipstick tube bolt

6 Nm

4.4 lbf.ft

Oil pressure switch

14 Nm

10 lbf.ft
