Emission control - V8

TORQUE WRENCH SETTINGS

06-6

Emission control - Td6

Emission control - V8

+ Apply anti-seize compound to threads

TORQUE DESCRIPTION

METRIC

IMPERIAL

Depression valve Allen screws

8 Nm

6 lbf.ft

Injector harness screws

2 Nm

1.5 lbf.ft

EGR valve bolts

10 Nm

7 lbf.ft

EGR solenoid valve nuts

10 Nm

7 lbf.ft

EGR cooler Allen screws

25 Nm

18 lbf.ft

Intercooler hose assembly to EGR valve
Wait 10 minutes and re-torque intercooler hose assembly to EGR valve

6 NM
6 Nm

4.4 lbf.ft
4.4 lbf.ft

TORQUE DESCRIPTION

METRIC

IMPERIAL

SAI pump bolts:

l

Upper

l

Lower

22 Nm
5 Nm

16 lbf.ft
4 lbf.ft

SAI control valve to manifold bolts

10 Nm

7 lbf.ft

HO2S +

50 Nm

37 lbf.ft
