Gasket(s) - exhaust manifold - LH

MANIFOLD AND EXHAUST SYSTEM - V8

30-2-14 REPAIRS

Gasket(s) - exhaust manifold - LH

$% 30.15.17

Before disconnecting the battery, ensure all text and
cautions in the battery disconnection section are
observed.


 +

 GENERAL INFORMATION, Electrical

Precautions.

Remove

1. Position vehicle on lift.
2. Disconnect battery earth lead.

3. Release clips securing LH and RH pre-catalyst

HO2S harness leads.

4. Release clips securing LH and RH post catalyst

HO2S harness leads.

5. Support weight of exhaust with jack.

6. Remove 4 nuts securing front exhaust rubber

mountings to body.

M30 1093

M30 1094
