Air Conditioning System Precautions (page 3 of 3)

GENERAL INFORMATION

03-31

Refrigerant oil

Refrigerant oil easily absorbs water and must not
be stored for long periods. Do not pour unused
refrigerant oil back into the container. Always
use an approved refrigerant oil.


 +

 CAPACITIES, FLUIDS, LUBRICANTS

AND SEALANTS, Lubrication.

When replacing components in the A/C system,
drain the refrigerant oil from the component being
replaced into a graduated container. On assembly,
add the quantity of refrigerant oil drained to the new
component.

Compressor

A new compressor is sealed and pressurised with
Nitrogen gas. When fitting a new compressor, slowly
release the sealing cap; gas pressure should be
heard to vent as the seal is broken.

CAUTION: A new compressor should always be
sealed and could be pressurised with nitrogen
gas. To avoid possible oil loss, release the
sealing cap(s) slowly. Do not remove the cap(s)
until immediately prior to connecting the air
conditioning pipes to the compressor.

Rapid refrigerant discharge

If the air conditioning system is involved in accident
damage and the system is punctured, the refrigerant
will discharge rapidly. The rapid discharge of
refrigerant will also result in the loss of most of the oil
from the system. The compressor must be removed
and all the remaining oil in the compressor drained
and refilled as instructed in the air conditioning
section of this manual.

Precautions for refrigerant recovery, recycling
and recharging
When the air conditioning system is recharged, any
existing refrigerant is first recovered from the system
and  recycled. The system is then charged with the
required weight of refrigerant and volume of
refrigerant oil.

WARNING: Refrigerant must always be recycled
before re-use to ensure that the purity of the
refrigerant is high enough for safe use in the air
conditioning system.

Recycling should always be carried out with
equipment which is design certified by
Underwriter Laboratory Inc. for compliance with
SAE J1991. Other equipment may not recycle
refrigerant to the required level of purity.

A R134a Refrigerant Recovery Recycling
Recharging Station must not be used with any
other type of refrigerant.

Refrigerant R134a from domestic and
commercial sources must not be used in motor
vehicle air conditioning systems.

CAUTION: The system must be evacuated
immediately before recharging commences.
Delay between evacuation and recharging is not
permitted.

Air Conditioning Compressor Replacement
A new compressor is supplied filled with a full charge
(X cm

3

) of refrigerant oil.



 +

 CAPACITIES, FLUIDS, LUBRICANTS

AND SEALANTS, Capacities.A calculated quantity
of oil must be drained from the new compressor
before fitting. To calculate the quantity of oil to be
drained:

1 Remove the drain plug from the old

compressor.

2 Invert the compressor and gravity drain the oil

into a calibrated measuring cylinder. Rotate the
compressor clutch to ensure the compressor is
completely drained.

3 Note the quantity of oil drained (Y cm

3

).

4 Calculate the quantity of oil to be drained from

the new compressor using the following
formula:

X cm

3

 — (Y cm

3

 + 20 cm

3

) = Q cm

3

5 Remove the drain plug from the new

compressor and drain Q cm

3

 of oil. Fit and

tighten the compressor drain plug.
