Front and rear suspension

GENERAL DATA

04-14

Front and rear suspension

* Measurement taken with vehicle at unladen weight and suspension in 'on road' setting.

Type - Front

Independent, Macpherson struts with air springs, gas tube dampers,
height sensors and anti-roll bar

Type - Rear

Independent with air springs, gas tube dampers, height sensors and
anti-roll bar

Nominal height from hub centre to wheel arch (not
liner):*

⇒

 Front

⇒

 Rear

493

±

 2 mm (19.4 in

±

 0.08 in)

483

±

 2 mm (19.0 in

±

 0.08 in)
