Finisher - tailgate - lower

EXTERIOR FITTINGS

76-2-18 REPAIRS

Roof moulding

$% 76.43.68

Remove

1. Carefully raise the front edge of moulding,

release from 11 clips and remove moulding.

2. Remove 11 clips from roof panel.

Refit

1. Clean roof channel.
2. Fit clips to roof panel.
3. Fit moulding and secure to clips.

Finisher - tailgate - lower

$% 76.43.99

Remove

1. Carefully release 7 clips securing tailgate

finisher to body. Remove finisher.

CAUTION: Always protect paintwork and
glass when removing trim finishers.

NOTE: Do not carry out further dismantling if
component is removed for access only.

2. Remove 7 clips from tailgate finisher.
3. Noting fitted position remove and discard 4

adhesive backed clips from finisher.

M76 4315
