Sensor - camshaft position (CMP) - RH

ENGINE MANAGEMENT SYSTEM - V8

18-2-10 REPAIRS

Sensor - camshaft position (CMP) - RH

$% 18.30.26

Before disconnecting the battery, ensure all text and
cautions in the battery disconnection section are
observed.


 +

 GENERAL INFORMATION, Electrical

Precautions.

Remove

1. Disconnect battery earth lead.
2. Remove air intake hose.

 +

 ENGINE MANAGEMENT SYSTEM -

V8, REPAIRS, Hose - air flow meter to
throttle body.

3. Cut 3 cable ties to release CMP sensor

harness.

4. Disconnect multiplug from CMP sensor.

5. Remove bolt securing CMP sensor and remove

sensor. Discard 'O' ring.

Refit

1. Clean CMP sensor and mating face.
2. Fit new 'O' ring.
3. Fit CMP sensor, fit bolt and tighten to 10 Nm (7

lbf.ft).

4. Secure CMP sensor harness with 3 cable ties.
5. Connect multiplug to CMP sensor.
6. Connect air intake hose.

 +

 ENGINE MANAGEMENT SYSTEM -

V8, REPAIRS, Hose - air flow meter to
throttle body.

7. Connect battery earth lead.
8. If a replacement sensor has been fitted, re-set

adaptions using TestBook/T4.

M86 5760

M86 5747
