Sensor - brake pedal position

ENGINE MANAGEMENT SYSTEM - V8

REPAIRS 18-2-23

Sensor - brake pedal position

$% 19.75.35

Remove

1. Release brake pedal position sensor from

holder, disconnect multiplug and remove
sensor.

2. Remove holder from pedal bracket.

Refit

1. Fit holder to pedal bracket.
2. Position brake pedal position sensor, connect

multiplug and secure to holder.

3. With brake pedal released, ensure brake pedal

position sensor is in contact with operating tang
on brake pedal.

4. If a replacement sensor has been fitted, re-set

adaptions using TestBook/T4.
