Anti-Freeze Concentration

CAPACITIES, FLUIDS, LUBRICANTS AND SEALANTS

09-2

Fluids

Anti-freeze
Use only Texaco anti-freeze coolant (AFC). This is
an ethylene glycol based anti-freeze (containing no
methanol) with silicate non-phosphate corrosion
inhibitors, to protect the cooling system

CAUTION: If Texaco AFC is unavailable, use any
ethylene glycol based anti-freeze (containing no
methanol) with silicate non-phosphate corrosion
inhibitors.

 The cooling system should be drained, flushed and
refilled with the correct amount of anti-freeze solution
at the intervals given on the Service Maintenance
Check Sheet.

After filling with anti-freeze solution, attach a warning
label to a prominent position on the vehicle stating
the type of anti-freeze contained in the cooling
system to ensure that the correct type is used for
topping-up.

Brake fluid
Use only Shell DOT 4 ESL brake fluid.

PAS fluid
Use only Texaco Cold Climate PSF 14315 fluid.

Air conditioning
Use only refrigerant HFC-R134a.

Refrigerant oil

Use only Nippon Denso ND-oil 8.

Refrigerant oil absorbs water and must not be stored
for long periods. Do not pour unused oil back into the
container.

NOTE: The total quantity of refrigerant oil in the
system is 110 cc (3.8 fl.ozs).

CAUTION: Do not use any other type of
refrigerant oil.

Anti-Freeze Concentration

The overall anti-freeze concentration should not fall,
by volume, below 50% to ensure that the anti-
corrosion properties of the coolant are maintained.
Anti-freeze concentrations greater than 60% are not
recommended as cooling efficiency will be impaired.

The following recommended quantities of anti-freeze
will provide frost protection to -36

°

C (-33

°

F):

Engine - Td6

Engine - V8

Concentration

50%

Amount of Anti-freeze to refill
system:

5.5 litres (11.6 US

pints)

Concentration

50%

Amount of Anti-freeze to refill
system:

6.5 litres (13.75 US

pints)
