Light Check Module (LCM) (page 3 of 5)

LIGHTING

86-2-10 DESCRIPTION AND OPERATION

LCM Harness Connector C0937 Pin Details

LCM Harness Connector C2039 Pin Details

LCM Harness Connector C2040 Pin Details

Pin No.

Description

Input/Output

1

Trailer module brake/right turn (NAS only)

Output

2

LH tail lamp

Output

3

Front RH side lamp

Output

4

Front RH fog lamp

Output

5

Rear LH number plate lamp

Output

6

Front RH direction indicator lamp

Output

7

Ground

–

8

Rear LH direction indicator lamp

Output

9

Rear RH fog guard lamp

Output

10

Brake lamps

Output

11

LH main beam

Output

12

Rear RH number plate lamp

Output

13

RH dipped beam

Output

14

RH side repeater lamp

Output

15

Battery power supply

Input

Pin No.

Description

Input/Output

1

Interior illumination

Output

2

Ground

–

3

RH main beam

Output

4

Front LH side repeater lamp

Output

5

Front and rear LH side markers (NAS only)

Output

6

LH dipped beam

Output

7

Front LH fog lamp

Output

8

Battery power supply

Input

9

LH and RH reverse lamps

Output

10

Bi-xenon control units

Output

11

Front LH direction indicator lamp

Output

12

Rear RH direction indicator lamp

Output

13

Front and rear RH side markers (NAS only)

Output

14

Rear LH fog guard lamp

Output

15

Trailer module brake/left turn (NAS only)

Output

Pin No.

Description

Input/Output

1

Lighting switch illumination

Output

2 to 6

Not used

–

7

Hazard warning switch on selection

Input

8

Front fog lamp switch

Input

9

Not used

–

10

Washer fluid level sensor

Input

11 and 12

Not used

–

13

Auxiliary power supply

Input

14 and 15

Not used

–

16

Illumination dimmer switch

Input

17

RH tail lamp

Output
