Circuit Protection
Operation of the lamps is performed using overload proof Metal Oxide Semiconductor Field Effect Transistors
(MOSFETs). The MOSFETs have a diagnostic output for bulb monitoring and can detect overload, load interruption
with the lamps switched on and short circuit to positive with the lamps switched off.

The MOSFETs are protected against short circuits, removing the requirement for the lamps circuits to be protected
by fuses. The MOSFETs respond to heat generated by increased current flow caused by a short circuit. Normally this
would cause the fuse to blow. The MOSFETs react to the heat increase and cut the supply to the affected circuit. Once
the fault has been rectified or the MOSFET has cooled, the MOSFET will automatically reset and operate the circuit
normally.

If an overload occurs, the current flow is dependant on the temperature of the related MOSFET and can be up to 20
times the rated current of the lamp. The MOSFET heats up and deactivates the load applied to the circuit. When the
MOSFET cools the circuit is once again reactivated. This thermal cycling occurs continuously in the event of an
overload occurring.

The brake switch is also monitored by the LCM. If the LCM detects a short circuit to ground in the switch circuit it
activates messages to the driver in the message centre. These messages will display switch defective and LH and
RH stop lamp defective. The brake switch is also monitored when the ignition is in position II. The LCM checks the
acceleration speed of the vehicle (via bus messages). If the vehicle is accelerating and the brake switch is still active
after 10 seconds, the LCM starts a timer. If, after 2 minutes, the brake switch is still active and the vehicle is moving,
the LCM activates defective switch messages in the instrument pack message centre.
