AIR CONDITIONINGRefrigerant System Component Location
AIR CONDITIONING
DESCRIPTION AND OPERATION
82-1
AIR CONDITIONING
DESCRIPTION AND OPERATION
Refrigerant System Component
Location
1 High pressure servicing connection
2 Low pressure servicing connection
3 Thermostatic expansion valve
4 Evaporator
5 Receiver drier module
6 Condenser
7 Compressor
