Locking and Alarm Component Layout –
Sheet 1 of 2
1 Volumetric sensor
2 Alarm LED
3 Bonnet switch
4 BBUS
5 Door latch
6 Fuel filler flap actuator
7 Lower tail door latch relay
8 Ignition key/remote handset
9 Lower tail door release switch
10 Upper tail door external release switch
11 Upper tail door latch
12 Lower tail door latch
13 RF receiver/antenna amplifier
