Manual Gearbox – PG1

TORQUE WRENCH SETTINGS

06-19

Manual Gearbox – PG1

+ Apply sealant, Part No. STC 50552 to threads of 2 top bolts

TORQUE DESCRIPTION

METRIC

IMPERIAL

Clutch slave cylinder mounting bracket to gearbox bolts

25 Nm

18 lbf.ft

Drain plug

35 Nm

26 lbf.ft

Filler / level plug

35 Nm

26 lbf.ft

1st. gear switch

24 Nm

18 lbf.ft

Front cover plate to gearbox bolt and nut

9 Nm

7 lbf.ft

Gearbox to engine bolts

+

80 Nm

59 lbf.ft

Gearbox to sump bolts

45 Nm

33 lbf.ft

Gear change steady rod to mounting bracket bolt

25 Nm

18 lbf.ft

Lifting bracket to gearbox bolt

45 Nm

33 lbf.ft

LH engine mounting to gearbox bolts

65 Nm

48 lbf.ft

LH engine mounting to gearbox bolts

80 Nm

59 lbf.ft

Reverse light switch

24 Nm

18 lbf.ft
