Manual Gearbox – Getrag

TORQUE WRENCH SETTINGS

06-20

Manual Gearbox – Getrag

+ Apply sealant, Part No. STC 4600 to threads

TORQUE DESCRIPTION

METRIC

IMPERIAL

Earth lead to gearbox bolt

25 Nm

18 lbf.ft

Engine LH mounting to body bolts (KV6)

48 Nm

35 lbf.ft

1st gear switch to gearbox

24 Nm

18 lbf.ft

Gearbox drain plug

35 Nm

26 lbf.ft

Gearbox casing end cover Torx bolts

25 Nm

18 lbf.ft

Gearbox filler / level plug

35 Nm

26 lbf.ft

Gearbox closing plate bolts

10 Nm

7 lbf.ft

Gearbox to engine bolts

85 Nm

63 lbf.ft

Gearbox to LH engine mounting bolts (KV6)

85 Nm

63 lbf.ft

Gear change cover bolts

25 Nm

18 lbf.ft

Gearbox mounting bracket to gearbox bolts

85 Nm

63 lbf.ft

Gearbox mounting bracket to gearbox bolts

100 Nm

74 lbf.ft

Gearbox mounting bracket to LH engine mounting through bolt

100 Nm

74 lbf.ft

Gearbox to engine bolts

85 Nm

63 lbf.ft

Gearbox rear cover Torx bolts

+

25 Nm

18 lbf.ft

Gear change cover to selector shaft Torx bolts

+

25 Nm

18 lbf.ft

LH engine mounting to gearbox bracket bolts

100 Nm

74 lbf.ft

Release bearing sleeve bolts

12 Nm

9 lbf.ft

Reverse lamp switch to gearbox

24 Nm

18 lbf.ft
