Seal - drive shaft - LH - K1.8

INTERMEDIATE REDUCTION DRIVE

41-24

REPAIRS

Seal - drive shaft - LH - K1.8

$% 41.29.08

Remove

1. Remove LH drive shaft.

 +

 DRIVESHAFTS, REPAIRS, Shaft

with both joints - LH.

2. Carefully remove oil seal from differential

housing, discard oil seal.

Refit

1. Thoroughly clean oil seal recess in differential

housing, splines and oil seal running surface on
drive shaft.

2. Fit handle LRT-37-027 into seal replacer

adaptor, LRT-37-032.

3. Position new oil seal onto LRT-37-032 with

sealing lip facing towards differential housing.

4. Carefully drift oil seal into housing until fully

seated in recess.

5. Fully insert oil seal protector tool, Unipart TRV

100060, into differential oil seal so that oil seal
lip is protected and that the split end of tool is
butted correctly.

6. Fit LH drive shaft.

 +

 DRIVESHAFTS, REPAIRS, Shaft

with both joints - LH.
