Interface ECU - cruise control - KV6

FUEL DELIVERY SYSTEM - PETROL

REPAIRS 19-2-43

ECU - cruise control - KV6

$% 19.75.49

Remove

1. Slide RH front seat fully rearwards.

2. Remove 2 screws securing ECU cover.
3. Remove cover.
4. Release interface ECU from bracket and move

aside.

5. Remove 2 screws securing cruise control ECU.
6. Disconnect multiplug from ECU and remove

ECU.

Refit

1. Connect multiplug to ECU.
2. Position ECU and tighten screws.
3. Secure interface ECU to bracket.
4. Fit ECU cover and secure with screws.
5. Position seat to mid position.

Interface ECU - cruise control - KV6

$% 19.75.55

Remove

1. Slide RH front seat fully rearwards.

2. Remove 2 screws securing ECU cover.
3. Remove cover.
4. Release interface ECU from bracket,

disconnect multiplug and remove ECU.

Refit

1. Position ECU, connect multiplug and secure

ECU to bracket.

2. Fit ECU cover and secure with screws.
3. Position seat to mid position.
