RESTRAINT SYSTEMSSRS Control Diagram · page 2 of 2
RESTRAINT SYSTEMS
DESCRIPTION AND OPERATION
75-3
1 Ignition switch
2 Fuse 8, passenger compartment fusebox
3 Fuse 36, passenger compartment fusebox
4 Driver's airbag module
5 Rotary coupler
6 Airbag DCU (pre 2002 MY version shown)
7 Passenger's airbag module
8 Seat belt pretensioners
9 Diagnostic socket
10 Instrument pack
