REAR SUSPENSIONRear Suspension Component Location
REAR SUSPENSION
DESCRIPTION AND OPERATION
64-1
REAR SUSPENSION
DESCRIPTION AND OPERATION
Rear Suspension Component Location
RH Rear suspension shown, LH is mirror image
1 Adjustable transverse link
2 Damper
3 Road spring
4 Rear subframe
5 Fixed transverse link
6 Trailing link
7 Drive shaft
8 Brake and hub assembly
