Instrument Pack Connector Details (page 2 of 2)

INSTRUMENTS

DESCRIPTION AND OPERATION

88-15

Connector C0230

The following table shows pin inputs/outputs for connector C0230.

Pin No.

Description

Input/Output

1

Seat belt warning signal

Input

2

Not used

-

3

Not used

-

4

Engine speed signal

Input (PWM)

5

Cruise active signal

Input (digital)

6

Not used

-

7

1st gear input (manual gearbox only)

Input (digital)

8

A/C pressure sensor (power supply)

Output

9

A/C pressure sensor signal (System pressure)

Input (analogue)

10

A/C pressure sensor earth

Output

11

Diagnostic ISO 9141 K Bus (serial)

Input/Output

12

CAN + (serial)

Input/Output

13

CAN + (serial)

Input/Output

14

Rear fog lamp active signal

Input

15

Trailer lamp failure signal

Input

16

Not used

-

17

Not used

-

18

Not used

-

19

Not used

-

20

A/C evaporator temperature signal

Input (analogue)

21

Fuel level sender signal

Input (analogue)

22

Not used

-

23

Permanent battery supply (13.4 V nominal)

Input

24

Earth

Input

25

CAN – (serial)

Input/Output

26

CAN – (serial)

Input/Output
