82 - AIR CONDITIONING: DESCRIPTION AND OPERATION
- Make
- Land Rover
- Model
- Range Rover P38
- Section
- DESCRIPTION AND OPERATION
82 - AIR CONDITIONING
AIR CONDITIONING
3
DESCRIPTION AND OPERATION
Heating and distribution components
20. Heater unit
21. Heater matrix
22. Air to windscreen and front side window vents
23. Air to fascia centre vents, side vents, lap vent
(driver only) and rear face vents
24. Blower
25. Fresh/ Recirculated air servo
26. Air to front and rear footwells
27. LH temperature servo
28. Distribution servo
29. Fresh air inlet and pollen filter
