86 - ELECTRICALLOAD SPACE LAMP
background image

ELECTRICAL

21

REPAIR

INTERIOR LAMP ASSEMBLY

Service repair no - 86.45.13

Remove

1. Remove lamp lens.
2. Remove 2 screws securing lamp to roof.

3. Release lamp assembly. Disconnect multiplug.

Remove lamp.

Refit

4. Reverse removal procedure.

LOAD SPACE LAMP

Service repair no - 86.45.16

Remove

1. Release lamp from tailgate.
2. Disconnect leads. Remove lamp.

Refit

3. Reverse removal procedure.
