Windshield Wiper Motor (page 2 of 2)

Make
Land Rover
Model
Discovery LR3/Disco 3
501-16 Wiper And WashersWindshield Wiper Motor · page 2 of 2
background image







bolts.

Install the windshield wiper motor and linkage.



Tighten the bolts to 6 Nm (4 lb.ft).



Connect the electrical connector.



Install the clips.

3 .



Install the plenum chamber panel. For additional information, refer to

Plenum Chamber (80.15.62)



(Section 412-01)
