Windshield Washer Reservoir (page 3 of 3)

Make
Land Rover
Model
Discovery LR3/Disco 3
501-16 Wiper And WashersWindshield Washer Reservoir · page 3 of 3
background image









Connect and secure the electrical connectors.



Connect the hoses.



Install the bolts and tighten to 6 Nm (4 lb.ft).

4 .

  Install the windshield washer reservoir filler neck.



Lubricate the seal.



Secure in the clip.

5 .



Install the front bumper. For additional information, refer to

Front Bumper (76.22.49)

 (Section 501-

19)
