operating range is reduced. The nominal life of the battery is approximately 14 years.

The key head has three buttons for operation of the CLS and the personalized feature, as follows:


A lock button, for locking and superlocking of the vehicle.
An unlock button, for unlocking the vehicle.
A personal button, for operating the personalized feature, which can be programmed to trigger a panic alarm,
operate the headlamp courtesy delay or remotely raise and lower the suspension. Programming the personalized
feature with a different function automatically overwrites the previous function. The personalized feature is
programmed with the key removed from the ignition switch, as follows: Panic alarm. Push and hold the personal
button, then push and hold the hazard flasher switch. After a confirmation chime sounds on the instrument cluster
speaker, release the personal button and the hazard flasher switch. Push and release the hazard flasher switch
again, to cancel the hazard flashers. Headlamp courtesy delay. Push and hold the personal button, then activate
the main beam flash switch (pull switch towards you). After a confirmation chime sounds on the instrument cluster
speaker, release the personal button and the main beam flash switch. Suspension. Push and hold the personal
button, then use the air suspension switch to select a different ride height. After a confirmation chime sounds on
the instrument cluster speaker, release the personal button and the air suspension switch. Programming the
personal button to operate the air suspension must take place within 60 seconds of turning the ignition off. The air
suspension switch position is relayed to the CJB (central junction box) on the CAN (controller area network)
systems, which power down 60 seconds after the ignition is switched off.

Panic alarm. Push and hold the personal button, then push and hold the hazard flasher switch. After a
confirmation chime sounds on the instrument cluster speaker, release the personal button and the hazard
flasher switch. Push and release the hazard flasher switch again, to cancel the hazard flashers.
Headlamp courtesy delay. Push and hold the personal button, then activate the main beam flash switch
(pull switch towards you). After a confirmation chime sounds on the instrument cluster speaker, release the
personal button and the main beam flash switch.
Suspension. Push and hold the personal button, then use the air suspension switch to select a different
ride height. After a confirmation chime sounds on the instrument cluster speaker, release the personal
button and the air suspension switch. Programming the personal button to operate the air suspension must
take place within 60 seconds of turning the ignition off. The air suspension switch position is relayed to the
CJB (central junction box) on the CAN (controller area network) systems, which power down 60 seconds
after the ignition is switched off.

The ignition keys are externally identical for all markets, but differ in the frequency and power at which the RF transmitter
in the key head operates. The RF transmitters operate at 433 MHz, 315 MHz or 315 MHz low power.

Each ignition key has a unique identification which is determined by the transponder in the key head. Every RF signal
from the ignition key contains the identification code and a rolling code. The CJB (central junction box) checks the codes
and only responds if the signal is from a valid ignition key. During vehicle production, the identification code of each
ignition key supplied with the vehicle is programmed into the CJB (central junction box) , and the rolling codes in the
ignition key and the CJB (central junction box) are synchronized. A total of 30 'slots' are available in the CJB (central
junction box) software to allow for replacement and additional ignition keys. In service, T4 can be used to communicate
with the CJB (central junction box) for the following:


Identify ignition key allocation within the CJB (central junction box) .
Enable new ignition keys.
Disable ignition keys.
Re-enable a previously disabled ignition key.

If the vehicle lockset is replaced, the keys supplied with the new lockset must be enabled and the old keys disabled.

If the rolling code of an ignition key loses synchronisation with the CJB (central junction box) , the remote operating
functions will cease to operate. Synchronisation can be restored by starting the engine with the unsynchronized ignition
key and allowing the engine to run for a minimum of 6 minutes.
