501-11 Glass Frames And Mechanisms: Description And Operation (page 2 of 11)


The tempered glass tinted green rear window is bonded to the upper tail doorframe using PU sealant. Fitted to the inner
surface of the rear screen are the heating elements and an extra FM antenna for diversity tuning, if fitted. For additional
information, refer to

Antenna

 (415-02 Antenna)



The heating element is connected by 2 lucar terminals while the antenna is connected to the vehicle by a twin and single
stud connector at the top of the screen. For additional information, refer to

Control Components

 (412-04 Control

Components)



WINDOW REGULATOR CONTROL

Windows Component Location

NOTE :

Item  Part Number

Description

1.

 -

Rear screen

2.

 -

Heated rear screen connectors

3

 -

Rear wiper motor aperture

4

 -

Sealant

LH drive shown, RH drive similar.
