501-08 Exterior Trim And OrnamentationRadiator Grill Removal
background image




Radiator Grille (76.55.03)

Removal



Installation



Published : Mar 3, 2004

1 .

  Remove the radiator grille.



Open the hood.



Release the 6 clips.

1 .

  To install, reverse the removal procedure.
