Liftgate Wiring Harness Removal

Liftgate Wiring Harness (86.70.84)

Removal

Published : Jul 16, 2004

1 .

  Open the liftgate and tailgate.

2 .

Disconnect the battery ground cable. For additional information, refer to

Specifications

 (Section 414-

00)

3 .

Remove the liftgate lower trim panel. For additional information, refer to

Liftgate Trim Panel

(76.34.11)

 (Section 501-05)

4 .

  Remove the liftgate upper trim panel.

Release the 4 clips.

5 .

  Remove the liftgate side trim panel.

Release the 5 clips.

Repeat the above procedure for the other side.

6 .

  Remove the rear headliner trim panel.

Release the 7 clips.

Disconnect the electrical connector.
