417-02 Interior Lighting: Description And Operation (page 2 of 9)

The interior lighting system comprises the following interior lamps:


Interior lamps
Map reading lamps
Glove compartment lamp
Luggage compartment lamps
Vanity mirror lamps
Footwell lamps
Puddle lamps
Ignition switch illumination

Interior Bulb/Type Rating

The following table shows the bulbs used for the interior lighting system and their type and specification.


CENTRAL JUNCTION BOX

The Central Junction Box (CJB) is an integrated unit located behind the instrument panel on the passenger side of the
bulkhead. The CJB contains fuses, relays and a number of microprocessors which control the power supply and
functionality of the interior lighting system and other vehicle systems.

The interior lamps are controlled by the CJB and have two modes of operation: manual and automatic. In the manual
mode the interior lamps can be switched on and off using the momentary and latching switches adjacent to each lamp or
disabled completely using the same switches. In the automatic mode the interior lamp functionality is controlled by the
CJB on receipt of various input signals.


Input signals

The CJB receives the following inputs which affect the operation of the interior lamps:


Ignition switch
Door switches
Tailgate switch
Glove compartment lamp switch
Unlock signal
Interior lamp switches
Map reading lamp switches
Battery saver relay
Vanity mirror lamp switches

Circuit Protection

The CJB provides circuit protection for all interior lamp circuits. The following interior lamp circuits are protected by Field
Effect Transistors (FETS):


Luggage compartment lamps
Footwell lamps
Ignition switch glow ring
Puddle lamps.

Bulb

Type

Rating

Front and rear interior lamps

Capless

5W

Front and rear map reading lamps

Capless

5W

Luggage compartment lamp

Capless

5W

Vanity mirror lamps

Festoon  14V 0.1A (0.14W)

Door puddle lamps

Capless

5W

Lower instrument panel footwell lamps  Capless

5W

Glove compartment lamp

Festoon

5W
