415-07 Video System: Description And Operation (page 5 of 5)

The second and third row seat passenger can use standard headphones to listen to audio from any of the sources fitted
to the vehicle. These include:


Television
CD
Radio
DVD

There are four remote audio control modules, two in the rear doors incorporating the rear window switches and two in the
rear load space each side of the third row seats.

The remote audio control modules allow the user to select which source to listen to. The remote controls cannot override
what the driver has selected to listen to. If the driver is listening to a CD the rear passenger cannot control the CD player.

The remote audio control modules allow the user to alter the volume in the head phones, change track/disc up/down or
repeat on a CD, change pre-set radio stations or tune up/down on the radio and television.


DVD AUTOCHANGER


The DVD autochanger is installed in the RH side of the luggage compartment, behind the trim panel. Up to six discs can
be stored in the DVD autochanger, in a removable magazine. The magazine is installed behind a sliding door in the front
face of the DVD autochanger. The magazine is removed from the DVD autochanger by pressing an eject button, which is
visible once the sliding door is open. Any combination of video DVDs, video CDs and audio CDs can be loaded in the
magazine.


ROOF MOUNTED SCREEN


The roof mounted screen is centrally located in the headlining between rows one and two. The screen has a resolution of
800 x 600. The rear screen displays in 16:9 wide-screen format

The roof mounted screen houses an infrared sensor. The infrared sensor receives the signals output by the remote
control and routes them via the MOST BUS to the RSE control module.

An ambient light sensor, in the bottom left edge of the screen, allows the system to automatically adjust the brightness of
the screen to compensate for changes in ambient light levels.


REMOTE CONTROL


The remote control is an IR type and can be used to control playback of the discs stored in the DVD autochanger.
