Battery Removal

Battery (86.15.01)

Removal

Installation

Published : Jul 22, 2004

1 .

  Secure the hood in the service position.

Release the support struts.

2 .

  Remove the battery cover.

3 .

Disconnect the battery ground cable. For additional information, refer to

Specifications

 (Section 414-

00)

4 .

  Disconnect the battery positive cable.

5 .

  Remove 2 bolts securing the battery clamp and remove the clamp.

6 .

  Remove the battery.

1 .

NOTE :

  Apply petroleum jelly to the battery terminals.

  To install, reverse the removal procedure.

Tighten the battery clamp bolts to 5 Nm (4 lb.ft).

Tighten the battery terminals to 5 Nm (4 lb.ft).
