413-01 Instrument Cluster: Description And Operation (page 5 of 17)



WARNING INDICATORS

The warning indicators are located in various positions in the instrument cluster. The warning indicators can be split into
two groups; self controlled and externally controlled.

Self controlled warning indicators are dependent on software logic within the instrument pack for activation. The pack
software controls the indicator check illumination at ignition on and all indicators whose operation is controlled by the
instrument cluster, the low fuel level warning indicator for example.

Externally controlled indicators are supplied with current from another system controlling module or illuminated by the
instrument cluster on receipt of a bus message from another subsystem module.

Some indicators are activated by an external subsystem module but the instrument cluster contains the control logic.
These indicators are shown in the following table as being both self and externally controlled.

The following table shows the available indicators and indicates if they are subject to an indicator check at ignition on and
if they are self or externally controlled.


21

 -

Odometer

22

 -

Trip meter display

23

 -

Trip reset button

24

 -

Selector lever position (automatic transmission only)

25

 -

CommandShift™/Sport mode indicator

26

 -

CommandShift™ gear position (automatic transmission only)

27

 -

Trailer indicator

28

 -

Low fuel indicator

29

 -

Message center

30

 -

ABS indicator

31

 -

Brake warning indicator (pad wear/low fluid/EBA/EBD)

32

 -

Auxiliary heating (non-functional - bulb check only)

33

 -

DSC/traction control indicator

34

 -

HDC active indicator

35

 -

Ambient light sensor

36

 -

Alarm indicator

37

 -

Transfer box low range indicator

38

 -

Air suspension warning indicator

39

 -

Tachometer

Indicator

Illumination
Color

Bulb Check

Self Controlled
(S)/Externally Controlled
(E)

Ignition/No charge

Red

No

E

Low oil pressure

Red

No

E

Glow plug active

Amber

* No (will illuminate at ignition
on to show glow plugs active)

E

MIL

Amber

* Yes

E

Seat belt

Red

No

E

SRS

Red

* Yes

E

Adaptive cruise control (if fitted)

Amber

No

E

Transfer box low range

Green

No

E

Air suspension

Amber / Red

Yes

E

HDC active

Green

No

E
