Fuel Pump Module Removal (page 2 of 4)
- Make
- Land Rover
- Model
- Discovery LR3/Disco 3
310-01A Fuel Tank And Lines- 4.0LFuel Pump Module Removal · page 2 of 4
5 .
Remove the fuel pump module access flange.
Disconnect the vent line.
Disconnect the fuel supply line.
Disconnect the 3 electrical connectors.
Remove and discard the seal.
6 .
Remove the fuel pump module.
Release the strap.
Release the fuel pressure regulator.
Disconnect the 2 fuel lines.
