309-00A Exhaust System 4.0L: Specifications

Specifications

Recommended Lubricant




General Specifications




Torque Specifications




* New bolts must be installed ** Apply suitable high temperature resistant anti-seize compound

Published : Feb 7, 2005

Item

Specification

HO2S threads  Use a high temperature resistant anti-seize compound

Item

Specification

Exhaust manifolds

Fabricated, air gapped with exhaust gas recirculation (EGR) tapping on left hand
manifold

Exhaust system

Twin, stainless steel pipes throughout with stainless steel mufflers

Catalytic converters -
type/location

Close coupled cascade - located in each down pipe with pre and post catalyst sensors
in both pipes

Description

Nm lb-ft

** HO2S

45  33

Catalytic converter retaining clamp

55  40

Catalytic converter to muffler nuts and retaining clamp 48  35

Tailpipe clamps

55  40

* Catalytic converter to exhaust manifold bolts

22  16
