309-00A Exhaust System 4.0LCatalytic Converter RH Removal · page 3 of 3
background image







4 .



Install the transmission crossmember. For additional information, refer to

Transmission Support

Crossmember (76.10.09 or 76.10.92)

 (Section 502-02)

5 .



   CAUTION: Make sure the H02S wiring harness is not twisted more than 180 degrees and is not

in contact with either the exhaust or driveshaft.

Connect the HO2S electrical connector.



Attach the HO2S wiring harness.

6 .

  Connect the battery ground cable. For additional information, refer to

Specifications

 (Section 414-00)
