308-07A Four-Wheel Drive Systems: Description And Operation (page 23 of 30)


The transfer box control module receives a gear position signal from the manual transmission gear position sensor and
publishes the status on the CAN bus. This is displayed in the odometer display, similar to how the automatic transmission
displays gear information.



On vehicles fitted with the low line instrument cluster, in place of the message centre there will be a status lamp, which
has the following logic:


Amber - Over temperature
Red - Failure, stop vehicle

The following table shows the faults that could possibly illuminate the transfer box status lamp on vehicles fitted with the
low-line instrument cluster:


'SPEED TOO HIGH FOR RANGE

CHANGE'

Range change request when vehicle speed too high

Single

'SELECT NEUTRAL FOR RANGE

CHANGE'

Range change request when lever not in neutral

Single

'PARK LOCK FAILURE APPLY

HANDBRAKE' (PARKBRAKE

US/CAN)

This alerts the driver that the automatic transmission park lock

function is inoperative due to transfer box out of high or low range.

Transfer box control module has stopped transmitting on the CAN

bus during a range change or while in neutral mode and as a result

the automatic transmission park lock function is inoperative

One per

second for

three

seconds

'RANGE CHANGE INOPERABLE'

Transfer box has detected a fault inhibiting a new range change.

Control unit has shut down due to thermal overload

Single

'CENTRE DIFF OVER TEMP

REDUCE SPEED'

Centre differential temperature is approaching the over heated

threshold

Single

'CENTRE DIFF FAULT –

TRACTION REDUCED'

Centre differential has failed - operating as an open differential

Single

'CENTRE DIFF FAULT –

TRACTION REDUCED'

Transfer box control module has stopped transmitting on the CAN

bus and defaults to open centre differential

Single

Odometer Display

Description

N

Transmission is in neutral

1

Transmission is in first gear

2

Transmission is in second gear

3

Transmission is in third gear

4

Transmission is in forth gear

5

Transmission is in fifth gear

6

Transmission is in sixth gear

R

Transmission is in reverse gear (Japan only)

Blank display

Transmission is between neutral and a gear

E

Transmission gear position sensor has a fault

Indication

Description

OFF

Transfer box is operating at normal working temperature

YELLOW

WARNING LAMP

ON

Transfer box temperature is approaching the over heated threshold

YELLOW

WARNING LAMP

ON

Transfer box has detected a fault, which affects the range change function (current range is still

maintained) or the centre differential has failed to open.

RED WARNING

LAMP ON

Transfer box has detected a fault which renders the transmission park lock function inoperative

due to out of range condition, OR centre differential has failed with a non-zero locking torque

YELLOW

WARNING LAMP

Transfer box control module has stopped transmitting on the CAN bus and defaults to open centre

differential
