303-06B Starting System- 4.4LSpecifications
Specifications
Starter Motor
Torque Specifications
** New patchlok bolt must be installed + New nut must be fitted
Published : Feb 4, 2005
Item
Specification
Starter motor:
Make
Denso
Type
RA - Pre-engaged
Voltage
12
Current consumption 1.8 kW
Description
Nm lb-ft
* Starter motor positive terminal nut
10 7
Starter motor bolts
45 33
** Lower steering column universal joint retaining bolt
25 18
Upper steering arm and brake line heat shield nuts and bolts 10 7
CAUTION: * Damage to the internal connections will result if this torque is exceeded
