Engine- Vehicles With Auto Transmission (page 3 of 13)
- Make
- Land Rover
- Model
- Discovery LR3/Disco 3
- Section
- Removal
15 .
Remove the radiator assembly. For additional information, refer to
Radiator (26.40.01)
(Section
303-03)
16 .
Remove the engine undershield.
17 .
Disconnect the thermostat housing coolant hoses. For additional information, refer to
Thermostat
(26.45.01)
(Section 303-03)
18 .
Remove the intake air shutoff throttle. For additional information, refer to
Intake Air Shutoff Throttle
(19.70.32)
(Section 303-04)
19 .
Remove the intake air shutoff throttle elbow.
Loosen the clip.
20 .
Disconnect the coolant top hose from the cylinder head coolant outlet assembly.
Release the clip.
