Timing Drive Components (page 10 of 10)

Make

Land Rover

Model

Discovery LR3/Disco 3

Section

In Vehicle Repairs

303-01B Engine- 4.4LTiming Drive Components · page 10 of 10









Remove the screw.

25 .



Install the CKP sensor. For additional information, refer to

Crankshaft Position (CKP) Sensor

(18.30.12)

 (Section 303-14)

26 .



Connect the battery ground cable. For additional information, refer to

Specifications

 (Section 414-

00)
