Fluid Cooler 4.0L 4.4L Removal

Power Steering Fluid Cooler - 4.0L/4.4L (57.15.11)

Special Service Tools


Spring lock decoupler
310-044


Removal

Published : Jun 24, 2004

1 .

Disconnect the battery ground cable. For additional information, refer to

Specifications

 (Section 414-

00)

2 .

Remove the front radiator grille. For additional information, refer to

Radiator Grille (76.55.03)

(Section 501-08)

3 .

  Remove the coolant expansion tank.

4 .

  Siphon the fluid from the power steering reservoir.

5 .

   CAUTION: Before disconnecting or removing the components, ensure the area around the joint

faces and connections are clean. Plug open connections to prevent contamination.

NOTE :

  Some fluid spillage is inevitable during this operation.

Using the special tool, disconnect the cooler line.

Position an absorbent cloth to collect fluid spillage.

6 .

  Disconnect the steering reservoir return hose.

Position an absorbent cloth to collect fluid spillage.

Release the clip.
