Brake Pedal and Bracket - Vehicles With: Manual Transmission (70.35.03)

Removal

NOTE:





Installation



Published: Jun 30, 2004



The brake pedal, clutch pedal and bracket is serviced as a complete assembly. The procedure to remove and
install the assembly is shown in the clutch pedal procedure.

1 .



Remove the clutch and brake pedal assembly. For additional information, refer to

Clutch Pedal

(33.30.02)

 (Section 308-02 )

1 .



Install the clutch and brake pedal assembly. For additional information, refer to

Clutch Pedal

(33.30.02)

 (Section 308-02 )
