206-04 Rear Brake Disc: Specifications




Specifications



Torque Specifications





Published : Jan 17, 2005

Item

Specification

Disc type

Ventilated

Disc diameter:



V6 Petrol and V6 Diesel engines

325 mm (12.7 in)

V8 Petrol engine

344 mm (13.5 in)

Disc thickness - All engines:



New

20.0 mm (0.78 in)

Service limit

17.0 mm (0.67 in)

Maximum disc run-out - disc installed  0.3 mm (0.012 in)

Caliper type

Sliding pin, single piston

Piston diameter

45.0 mm (1.7 in)

Pad minimum thickness

3.0 mm (0.12 in)

Brake pad wear warning lead:



Location

Rear right hand brake pad

Activates at

75% of pad life utilised

Description

Nm  lb-ft

Brake caliper bleed screw

14  10

Brake hose union

28  21

Brake disc Torx screw

35  26

Brake caliper anchor plate bolts  115  85

Brake caliper housing bolts

35  26

Road wheel nuts

140  103
