Brake Caliper Anchor Plate (page 3 of 3)

  Install the guide pins.

4 .

  Install the anchor plate.

Tighten the bolts to 115 Nm (85 lb.ft).

5 .

  Install the brake caliper housing and fit the top bolt.

Tighten the bolt to 35 Nm (26 lb.ft).

6 .

  Install the brake pads.

Install the 2 clips.

7 .

  Rotate the brake caliper downwards.

Tighten the bolt to 35 Nm (26 lb.ft).

8 .

  Connect the brake pad wear indicator sensor.

9 .

  Install the wheel and tire.

Tighten the wheel nuts to 140 Nm (103 lb.ft).
