Outer Cv Boot (47.10.03)

Outer Constant Velocity (CV) Joint Boot (47.10.03)

Removal

Installation

1 .

   WARNING: Do not work on or under a vehicle supported only by a jack. Always support the

vehicle on safety stands.

  Raise and support the vehicle.

2 .

  Remove the wheel and tire.

3 .

  Remove the halfshaft. For additional information, refer to

Halfshaft LH (47.10.01)

 (Section 205-04)

4 .

  Clamp the halfshaft in a vise.

5 .

  Remove and discard the CV joint boot retaining clamps.

6 .

  Slide the CV joint boot along the halfshaft to gain access to the joint.

7 .

  Using a drift against the inner part of the CV joint, remove the CV joint from the halfshaft.

Remove and discard the snap ring.

8 .

  Remove the outer CV joint boot.

1 .

  Clean the components.
