Halfshaft LH (47.10.01) (page 5 of 8)

   CAUTION: Ensure the ball joint seal is not damaged. A damaged seal will lead to the

premature failure of the joint.

Using the special tool, release the upper arm ball joint.

Remove and discard the retaining nut.

12 .

   CAUTION: The lower arm ball joint can be damaged by excessive articulation. The wheel

knuckle must be fully supported at all times. Do not allow the wheel knuckle to hang on the lower
arm. Failure to follow this instruction will result in damage to vehicle.

Using the special tools, release the halfshaft from the wheel hub.

13 .

  Release the halfshaft from the wheel knuckle.

14 .

  Release the halfshaft from the differential housing.

15 .

  Remove the halfshaft.

Raise the stabilizer bar to allow removal of the halfshaft.
